Blue Sea 8102 ELCI GFCI Panel AC 2 Position [8102]
Save $230.27
Original price
$773.22
Original price
$773.22
-
Original price
$773.22
Original price
$773.22
Current price
$542.95
$542.95
-
$542.95
Current price
$542.95
ELCI Main 30A Double Pole + 2 Positions with Voltmeter
- One 30A AC ELCI Main Residual Current Circuit Breaker, leakage trip amperate - 30 mA
- ELCI provides overcurrent and leakage protection per ABYC E-11 for whole boat shore power protection
- Red " Reverse Polarity" LED
- All circuit label positions are backlit
- "ON" indicating LEDs
Specifications
Positionst2
Nominal Voltaget120V AC
Leakage Trip Ampst30mA
Heightt5.25" (133.35mm)
Widtht 7.50" (190.5mm)
Deptht3.50" (88.9mm)
Weightt2.25lb (1.02kg)
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.
Specifications:
- AC/DC: AC
- Max Breaker Quantity: 2
- Voltage: 120v
- Box Dimensions: 5"H x 9"W x 11"L WT: 2.3 lbs
- UPC: 632085081027
Quick Guide (pdf)
Owner's Manual (pdf)
